WIKA NPT 1/2 Analogue Pressure Gauge 0.04bar Bottom Entry 160mm Outside Diameter - 40007651
Accurate WIKA analogue pressure gauge for low pressure measurement up to 0.04bar.
Manufacturer part number: 40007651
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Maximum Pressure Measurement = 0.04bar
Mounting Type = Bottom Entrybar
Display Type = Analogue
Connection Size = NPT 1/2
Gauge Outside Diameter = 160mm
Series = 612.20
The WIKA model 612.20 capsule pressure gauge is based upon the proven capsule measuring system. The capsule measuring principle is particularly suitable for low pressures. On pressurisation, the expansion of the capsule element, proportional to the incident pressure, is transmitted to the movement and indicated. The modular design enables a multitude of combinations of case materials, process connections, nominal sizes and scale ranges. Due to this high variance, the instrument is suitable for use in a wide range of applications within industry.Robust design Zero point setting in front Case from stainless steel
