Key Features:
- Designed for light sailing applications, particularly suitable for dinghies.
- Features a composite sheave and 316L stainless steel cheeks for durability.
- Pivoting design intended for stanchion applications, such as furling system lines.
Technical Specifications:
- Rope Size: Compatible with ropes ranging from 8 to 10 mm in diameter.
- Sheave Diameter: 25 mm.
- Length: 95 mm.
- Width: 53 mm.
- Thickness: 21 mm.
- Working Load: 280 kg.
- Breaking Load: 400 kg.
- Weight: 70 g.
Materials:
- Sheave: Composite material.
- Cheeks: 316L stainless steel.
Dimensions:
- Length: 95 mm.
- Width: 53 mm.
- Thickness: 21 mm.
- Sheave Diameter: 25 mm.
Compatibility Information:
- Ideal for use with ropes of 8 to 10 mm diameter.
- Designed for stanchion applications, particularly for furling system lines.
Additional Details:
- The working load is specified for nautical applications, while the breaking load is provided for industrial applications, with a safety factor of 5 times the breaking load.
