Key Features:
- Self-locking mechanism prevents accidental unscrewing due to vibrations.
- Forged from grade 316L stainless steel for enhanced durability and corrosion resistance.
- CE marked, indicating compliance with European safety standards.
Technical Specifications:
- Working Load (WL): 600 kg (1,320 lbs)
- Breaking Load (BL): 1,500 kg (3,300 lbs)
- Weight: 27 g
Dimensions:
- A: 30 mm
- B: 12 mm
- C: 6 mm
- D: 12 mm
- D Diameter: 6 mm
- E: 5 mm
- F: 45 mm
Materials:
- Grade 316L stainless steel
Compatibility Information:
- Ideal for applications requiring a 90° angle twist setup.
- Commonly used to attach unarticulated parts, such as blocks on rails or in purchase systems.
Additional Details:
- The pin is locked into one of the indentations, eliminating the risk of loosening due to vibrations.
- Suitable for both nautical and industrial applications, with a safety factor of 5 times the breaking load.
