Watson Smith 0.85L/min NPT 1/4 Female IP Converter, 3psi to 15 psi, 4-20mA input - 400100R

Input Signal = 4-20mA
Manufacturer Series = 100X, 101X
Flow Rate = 0.85L/min
Connection Size = NPT 1/4 Female
Connection Thread Standard = NPT
Maximum Operating Pressure = 15 psi
Maximum Operating Temperature = +85°C
Connection Thread Size = 1/4 in
Minimum Operating Pressure = 3psi
Minimum Operating Temperature = -40°C

*Inlet pressure must be at least 0.7 bar above output pressure. Standard Converters. These standard converters are reliable pneumatic fittings. This range has a 1/4 inch female port and includes mounting bracket and connector plug. There is minimal vibration from this converter and it also has the benefit of being sensitive to low pressures. Proportional converters have a glass reinforced nylon cover and nitrile diaphragms. This range of pneumatic pressure control proportional converters provide excellent pressure control providing oil free, dry air filtered to 5µm. Integral volume booster gives flow rates up to 4·72 dm ;sup>3 ;/sup>/s, 10scfm Response time typically 2 seconds (10-90%) Low supply pressure sensitivity 1/4 inch female port connection Supplied with DIN43650 connector plug
