Key Features:
- High-Precision Monitoring: Accurately calculates ampere-hours consumed and the state of charge of the battery by integrating the current flowing in or out.
- Comprehensive Display: Shows battery voltage, current, power, ampere-hours consumed, state of charge, time to go, and power consumption in watts.
- Programmable Alarms and Relays: Offers visual and audible alarms, and programmable relays to manage non-critical loads or initiate generator start when necessary.
- VE.Direct Communication Port: Enables connection to Victron Energy devices for enhanced monitoring and control.
- Wide Input Voltage Range: Supports systems with input voltages from 6.5 to 95 V.
- Low Power Consumption: Consumes minimal power, approximately 2.9 Ah per month (4 mA) at 12 V and 2.2 Ah per month (3 mA) at 24 V.
Technical Specifications:
- Voltage Range: 6.5 to 95 V DC
- Current Measurement Resolution: 10 mA (0.01 A)
- Accuracy:
- Voltage: ±0.01 V
- Current: ±0.01 A
- Ampere-Hours: ±0.1 Ah
- State of Charge: ±0.1%
- Time to Go: ±1 minute
- Temperature Range: -20°C to 50°C
- Display Dimensions:
- Front: 63 mm diameter
- Front Bezel: 69 x 69 mm
- Body Diameter: 52 mm
- Body Depth: 31 mm
- Relay Specifications: 60 V / 1 A
- Battery Capacity Range: 20 to 9999 Ah
- Warranty: 5 years
Materials:
Constructed with durable materials suitable for marine and off-grid applications, ensuring longevity and reliability.
Dimensions:
- Front: 63 mm diameter
- Front Bezel: 69 x 69 mm
- Body Diameter: 52 mm
- Body Depth: 31 mm
Compatibility Information:
Compatible with a wide range of battery types and sizes, making it suitable for various applications, including marine, off-grid, and industrial systems.
Additional Details:
- Installation: Features quick-connect terminals on the shunt's printed circuit board (PCB) for easy wiring. The shunt connects to the monitor via a standard RJ12 telephone cable.
- Included Accessories: Comes with a 10-meter RJ12 cable, a 2-meter battery cable with fuse, a dial for square or round display, a mounting ring for rear mounting, and screws for front mounting.
- Programming: Equipped with a quick installation menu and a detailed configuration menu with scrolling texts to assist users during setup.
