Key Features:
- Allows simultaneous charging of two or more batteries from a single alternator or battery charger without connecting the batteries together.
- Utilizes FET transistors, resulting in virtually no voltage loss.
- Voltage drop is less than 0.02 V at low currents and averages 0.1 V at higher currents.
- Includes a B+ power output to prevent alternator start issues.
Technical Specifications:
- Models Available:
- Argofet 100-2: 2 batteries, 100 A maximum charge current, 100 A maximum alternator current.
- Argofet 100-3: 3 batteries, 100 A maximum charge current, 100 A maximum alternator current.
- Argofet 200-2: 2 batteries, 200 A maximum charge current, 200 A maximum alternator current.
- Argofet 200-3: 3 batteries, 200 A maximum charge current, 200 A maximum alternator current.
- Connectors: M8 bolts.
- Dimensions: 65 x 120 x 200 mm.
- Weight: 1.4 kg.
Materials:
Constructed with high-quality materials to ensure durability and reliable performance.
Compatibility Information:
Compatible with various alternators and battery types, suitable for automotive, marine, and off-grid applications.
Additional Details:
When using ARGO FET Battery Isolators, it's advisable to use short cables with sufficient cross-sectional area to minimize voltage drop. For example, a 100 A current through a 50 mm² (AWG 0) cable of 10 m length results in a voltage drop of 0.26 V. Similarly, a 50 A current through a 10 mm² (AWG 7) cable of 5 m length results in a voltage drop of 0.35 V.
