Key Features:
- Designed for use with Ultraflex T85 steering system.
- Constructed with corrosion-resistant materials suitable for marine environments.
- Features all stainless steel cable output ends for enhanced durability.
- Provides minimal feedback for smooth steering control.
- Not compatible with boats equipped with engines exceeding the maximum horsepower rating of the boat.
- Available in various lengths to accommodate different boat sizes.
Technical Specifications:
- Steering Cable Stroke: 228 mm (9 inches)
- Lock-to-Lock Steering Wheel Turns: Approximately 3 turns
- Maximum Steering Wheel Diameter: 406 mm (16 inches)
- Minimum Steering Cable Bend Radius: 200 mm (7.9 inches)
Materials:
- High-quality stainless steel for cable output ends.
- Corrosion-resistant materials throughout the cable construction.
Dimensions:
- Available in multiple lengths, including 9', 13', 16', 20', 22', 24', 25', 27', and 28'.
- For example, a 9-foot cable measures approximately 2.74 meters in length.
Compatibility Information:
- Specifically designed for the Ultraflex T85 steering system.
- Also compatible with T71FC, T72FC, T73NRFC, T74NRFC, T81FC, and T83NRFC steering helms.
- Not compatible with T91, T93ZT, T101, or T103ZT steering systems.
Additional Details:
- Exceeds EN 28848 and ABYC P17 safety standards.
- Available in packages with ROTECH-V steering systems.
