Key Features:
- Versatile hose suitable for high-pressure cleaning operations and general discharge services using hot or cold water and various other fluids.
- Extremely resistant to aging and atmospheric conditions.
- Wide operating temperature range from -30°C to +100°C.
- Available in a wide range of diameters.
- Excellent mechanical properties.
- Resistant to many fluids.
- Attractive, well-finished appearance.
- Long service life.
Technical Specifications:
- Inner Tube: Black, smooth EPDM rubber.
- Reinforcement: Synthetic textile.
- Cover: Black, smooth EPDM for inner diameters (ID) from 12.7 to 25.4 mm; fabric impression for ID from 30 to 38 mm.
- Temperature Range: -30°C to +100°C.
- Standard/Approval: Compliant with ISO 1403 type 2 (except branding).
Dimensions and Performance:
The hose is available in various sizes, with specific dimensions and performance characteristics detailed in the technical documentation. For example, a hose with an ID of 12.7 mm has an outer diameter (OD) of 20.7 mm, a wall thickness of 4 mm, a working pressure of 20 bar, and a bursting pressure of 60 bar. The bending radius is 55 mm, and the weight is 10.8 kg per 40-meter length.
Materials:
- Inner Tube: EPDM (Ethylene Propylene Diene Monomer) rubber, known for its excellent resistance to aging, ozone, and weathering.
- Reinforcement: Synthetic textile, providing strength and flexibility.
- Cover: EPDM rubber, offering additional protection against environmental factors.
Compatibility Information:
Suitable for conveying hot or cold water and many other fluids. For specific chemical compatibility, refer to the chemical resistance table for EPDM.
