Key Features:
- Lightweight Design: At just 95 kg (209 lbs), this engine is the lightest in its class, ensuring easy handling and installation.
- Electronic Fuel Injection (EFI): Provides quick throttle response, excellent fuel economy, and smooth operation.
- High-Efficiency Charging System: Equipped with a 21-amp alternator for superior battery charging.
- Built-in Freshwater Flushing System: Simplifies routine engine flushing for maintenance.
- Variable Idling Speed Control: Allows trolling speed (RPM) to be adjusted in four levels from 650 to 950 RPM using the key-switch.
- Through-the-Prop Exhaust: Offers a quieter ride by directing exhaust through the propeller.
- Adjustable Steering Friction and Trim Tab: Reduces steering effort for a more comfortable boating experience.
Technical Specifications:
- Engine Type: 4-Stroke, 3 Cylinder
- Displacement: 866 cc (52.84 cu.in.)
- Bore x Stroke: 70 x 75 mm (2.75 x 2.95 in)
- Maximum RPM Range: 5,000 - 6,000 RPM
- Starting System: Electric Start
- Control Type: Remote Control or Tiller Handle
- Gear Shift: Forward - Neutral - Reverse
- Gear Ratio: 2.08:1
- Propeller Selection Range: 7" - 17"
- Transom Height: 15" (38 cm) or 20" (51 cm)
- Fuel Type: Unleaded Gasoline (87 Octane) or higher
- Oil Type: NMMA Certified FC-W® 4-Stroke Oil
- Oil Capacity: 2.4 L (0.63 US Gal.) with filter
- Fuel Tank Capacity: 25 L (6.6 US Gal.) Separate Fuel Tank
- Alternator Output: 12V, 252W, 21A
- Emissions Compliance: Ultra-low 3-star CARB emission approved
- Warranty: 5-Year Limited Warranty
Materials:
- Engine Housing: High-grade marine aluminum alloy for enhanced corrosion resistance.
- Water Pump Housing: Stainless steel for outstanding durability.
- Fuel Tank: Plastic 25-liter fuel tank included with fuel fittings and fuel line.
Dimensions:
- Length: Approximately 1,000 mm (39.4 inches)
- Width: Approximately 500 mm (19.7 inches)
- Height: Approximately 1,200 mm (47.2 inches)
- Weight: 95 kg (209 lbs)
Compatibility Information:
- Shaft Lengths: Available in short (15") and long (20") shaft lengths to fit various boat transom heights.
- Propeller Selection: Compatible with propellers ranging from 7" to 17" in diameter.
Additional Details:
- Color Options: Available in Aqua Marine Blue and Beluga White to match your vessel's aesthetics.
