Key Features:
- Designed for quick and secure connections in fluid and air transfer applications.
- Constructed from lightweight and corrosion-resistant aluminum.
- Equipped with stainless steel cam arms for enhanced durability.
- Compatible with Type A, E, F, and DP (Dust Plug) adapters of the same size.
- Not suitable for use with compressed air or steam.
Technical Specifications:
- Size: 1/2 inch
- Connection Type: Female Camlock to Female NPT Thread
- Material: Aluminum body with stainless steel cam arms
- Seal Material: NBR (Buna-N) gasket
- Maximum Operating Pressure: 250 PSI
- Temperature Range: -10°C to +80°C
Materials:
- Body: Aluminum alloy
- Cam Arms: Stainless steel
- Seal: NBR (Buna-N) rubber
Dimensions:
- Overall Length: Approximately 2 inches
- Adapter Length: Approximately 1.5 inches
- Distance Across Flats: Approximately 2.4 inches
- Distance Across Open Cam Arms: Approximately 5.2 inches
- Hose Shank Outer Diameter: Approximately 1.6 inches
Compatibility Information:
- Compatible with 1/2 inch male camlock fittings.
- Female NPT thread connects to 1/2 inch male NPT threaded pipes.
- Suitable for use with water, hydraulic oils, coolants, gasoline, and other petroleum products.
Additional Details:
- Ideal for applications requiring frequent hose changes, offering quick and secure connections.
- Not suitable for use with compressed air or steam.
