Key Features:
- Countersunk domed slotted head design for improved grip and reduced wood deformation during installation.
- Complies with DIN 95 standards (NFE 25-605, UNI 703) for professional quality and easy identification.
- Made from brass, offering high corrosion resistance, good electrical and thermal conductivity, and ease of machining.
Technical Specifications:
- Thread type: Wood screw thread according to DIN 7998.
- Available diameters (d): 2.5 mm, 3 mm, 3.5 mm, 4 mm, 5 mm.
- Head dimensions:
- dk (head diameter): 4.7 mm, 5.6 mm, 6.5 mm, 7.5 mm, 9.2 mm.
- k (head height): 1.5 mm, 1.65 mm, 1.93 mm, 2.2 mm, 2.5 mm.
- t (head recess depth): 1 mm, 1.2 mm, 1.4 mm, 1.6 mm, 2 mm.
- n (thread length): 0.6 mm, 0.8 mm, 0.8 mm, 1 mm, 1.2 mm.
Materials:
Brass, an alloy primarily composed of copper and zinc, known for its corrosion resistance, electrical and thermal conductivity, machinability, and fatigue resistance.
Dimensions:
Available in various lengths, depending on the chosen diameter. Specific length options can be selected during purchase.
Compatibility Information:
Suitable for wood applications requiring a countersunk domed slotted head screw.
