Telemecanique Sensors XCS-L Series Solenoid Interlock Switch, Power to Unlock, 24V dc, Actuator Included - XCSL761B3

IEC/EN 60947, EN 292, EN 60204, EN 1088. XCSL Solenoid Interlock Switch. Introducing the new XCS-L Solenoid Locking Safety Interlock Switches, this replaces the XCK-J series. The XCS-L switches perform the same functions as the XCK-J switch. However, many features that were optional are now standard on the XCS-L range. The XCS-L Safety Interlock Switches provide enhanced operator safety for heavy duty application. The switches have been designed in compliance with the standards currently in effect: IEC/EN 60947, EN 292, EN 60204, EN 1088 to ensure the safety of machine operators and operating reliability. Metallic or plastic housing User rotatable head Up to 6 contacts (up to 3 safety contacts + up to 3 electromagnet contacts) all positive opening Better resistance to forcible opening of actuating key 314.7 lbs (1400N) for plastic range and 674.4 lbs (3000N) for metallic range Cage clamps for quick and easy wiring Available conduit entries: " - 14 NPT or M20 x 1.5mm 3 conduit openings Mini Connectors available Available solenoid voltages 24 VAC/dc, 120 VAC or 230 VAC Rear emergency release - allows opening of door or interlock to escape from inside of machinery or work cells Uses same actuating keys as other XCS metal body safety interlocks All wiring enters switch through one conduit opening 2 LEDs Standard Protection rating of IP67
