Telemecanique Sensors XCS-E Solenoid Interlock Switch Actuator Included, Zinc Alloy - XCSE73117

Actuator Included = Yes
Safety Contacts = 2NC
Maximum DC Voltage = 250V
Connection Type = PG13.5
Housing Material = Zinc Alloy
Range = Preventa
IP Rating = IP67
Series = XCS-E
Depth = 146mm

Conforms to EN1088, EN60204. Actuators must be purchased separately, see Accessories table. Telemecanique Sensors XCSE Solenoid Interlock Switch. From Telemecanique Sensors this is the XCSE series of safety solenoid interlock switches providing you with the solution when running machinery and a guard or door stays closed. Interlock switches protect machine operators by stopping the equipment when the door or guard opens by withdrawing the actuator attached from the switch head. The XCSE solenoid interlock switch is ideal for use with heavy duty industrial machines with a low rundown time. Series Features. Key operated lock to allow authorised override of solenoid (key supplied) 2 LED indicators (orange/guard open, green/guard closed, key in locked position) Heavy duty metal compact style to IP67 Turret heads can be rotated through 360° in 90 steps 8 actuator entries and 1 tapped entry Contact rating 24 Vac/6 A; 110 Vac/3 A; 230 Vac/2 A; 24 Vdc/0.5 A for 1000000 operations 20N minimum operating force for positive opening Productivity is increased due to the third contact dedicated to diagnostics
