Telemecanique Sensors Pressure Switch, 0bar Min, 10bar Max, Analogue Output - XMLK010B2C21

Minimum Pressure Reading = 0bar
Maximum Pressure Reading = 10bar
Accuracy = ±0.3 %
Output Type = Analogue
Media Measured = Air, Fresh Water
Electrical Connection = DIN 43650A 4-Pin Male Connector
Response Time = 2 ms
Maximum Current = 20 mA
Supply Voltage = 24 V dc
Housing Material = Stainless Steel
IP Rating = IP65°C

OsiSense XMLK Pressure Sensors. Schneider Electric XMLK pressure transmitters are feature a ceramic pressure measuring cell and are available with various types of electrical connector and fluid connections. Deformation, caused by pressure, changes the resistance of the resistors of a Wheatstone bridge silk-screened on the ceramic. The change in resistance is then processed by the integrated electronics to provide an analogue output signal.
