Telemecanique Sensors OsiSense XC Series Plunger Limit Switch, NO/NC, IP66, IP67, DP, Plastic Housing, 240V ac Max, 10A - XCKT2102P16
Reliable plunger limit switch for industrial applications with IP66/IP67 rating.
Manufacturer part number: XCKT2102P16
GTIN: 3389110214383
Free shipping
Only Ships to: France, Monaco, Italy For shipping outside these regions, please contact customer support.
Actuator Type = Plunger
Pole and Throw Configuration = DP
Normal State Configuration = NO/NC
IP Rating = IP66, IP67
Maximum Current = 10A
Housing Material = Plastic
Maximum AC Voltage = 240V
Maximum DC Voltage = 250V
Series = OsiSense XC
Action Type = Snap Action
Length = 51mm
Depth = 30mm
Mechanical Life = 10000000Cycles
Telemecanique Limit Switches. Introducing Telemecanique XCKT range of limit switches and accessories. These Telemecanique limit switches are the perfect solution for a multitude of applications including escalators, electrical assembly equipment and material handling. A limit switch is commonly made up of an actuator head, switch body and receptacle, predominantly used as part of a control system within industrial applications such as those listed before. How does a limit switch work?. The limit switches function through a contact proximity sensor device that features an actuator that is mechanically linked to a set of output contacts. When an object comes into contact with the actuator, the device then operates the contacts to make or break the electrical connection.
