Telegartner TOC Series Male RJ45 Connector, Panel Mount, Cat6a Straight 8P8C -Way - J60026A0000

Ethernet Connector Type = RJ45 Connector
LAN Category = Cat6a
Mounting Type = Panel Mount
Number of Ways = 8P8C
Shield Type = Shielded
Orientation = Straight
IP Rating = IP68
Length = 68.7mm
Width = 36 (Dia.)mm
Series Number = J60026A0000
Contact Material = Brass (Shield Contact), Spring Steel
Contact Plating = Nickel

Connector standard to IEC 60603-7-51 (500 MHz) Category 6A: ANSI/TIA/EIA-568-C.2 Category 6: ISO/IEC 11801, DIN EN 50173-1 IP68 protection to IEC 60529. Telegärtner DataVoice TOC IP68 Outdoor Cat 6 RJ45 MFP8 T568B Plug Set. TOC IP68 outdoor Cat 6 RJ45 MFP8 T568B plug set suitable for use in harsh environment machine and plant engineering applications with a temperature range of -40 to +85°C. Installation requires just one turning movement to lock and seal the connection. This cat 6 RJ45 RJ45 MFP8 T568B plug set is suitable for10 Gigabit ethernet transmission acc. to IEEE 802.3an and PoE+ acc. to IEEE 802.3at and has a nickel plated brass housing, a clear PC UL94 V0 contact housing, 360° shielding and accepts a cable insulation diameter of 1.0 to 1.6mm and cable outer diameter of 4 to 9.5mm. An IP68 bulkhead plug protective cap is available separately, please see stock number ; 878-2498 878-2498
