Teledyne LeCroy T3VNA3200 Benchtop 100kHz to 3.2GHz Vector Network Analyzer

Form Factor = Benchtop
Frequency Range = 100kHz to 3.2GHz
Dynamic Range = 75dB
Number of Test Ports = 2
Test Port Connector Type = N Type Female
S-Parameters = S11, S21
Number of Sweep Points = 751
Trace Noise = 0.1dB
Sweep Rate = 1ms to 3200s
Time Domain Display Included = Yes
Test Port Power = -5dBm
IF Bandwidth = 10 kHz
Number of Test Receivers = 1
Port Bias-Ts = No
Plug Type = US/EU/UKV

Teledyne LeCroy T3VNA3200 Desktop Dual Vector Network/Spectrum Analyser, 9 kHz - 3.2 GHzThe Teledyne Test Tools T3VNA3200 Vector Network Analyser has a Vector Network Analysis frequency range of 100 kHz up to a maximum of 3.2 GHz and a Spectrum Analysis frequency range from 9 kHz up to a maximum of 3.2 GHz. The small footprint and easy user interface is augmented by a high performance specification with many advanced measurement functions and capabilities.Features & Benefits156 dBm/Hz Displayed Average Noise Level (Typ.) -98 dBc/Hz @10 kHz Offset Phase Noise (1 GHz, Typ.) Total Amplitude Accuracy < 1.2 dB Distance to fault capability using VNA time domain analysis as standard Calibration and Utility Kits as standard Standard Preamplifier Built-in Advanced Measurement capability as standard (CHP, ACPR, OBW, CNR, TOI, etc) 10.1 lnch WVGA (1024 x 600) Display 1 Hz Minimum Resolution Bandwidth (RBW) All-Digital IF Technology
