TE Connectivity Straight, Fluid Resistant Elastomer, 25mm - 202K232-25-0
Durable straight fluid resistant elastomer with strain relief and environmental seal.
Manufacturer part number: 202K232-25-0
Only Ships to: France, Monaco, Italy For shipping outside these regions, please contact customer support.
Type = Straight
Inside Diameter Primary = 25mm
Inside Diameter Secondary = 8mm
Adhesive Lined = No
Material = Fluid Resistant Elastomer
Number of Breakouts = 1
Minimum Operating Temperature = -75°C
Maximum Operating Temperature = +150°C
Shrunk Diameter Primary = 13.8mm
Shrunk Diameter Secondary = 3.3mm
Series = 202K2
General Purpose (Lipped) - 202K1 and 222K1 Series. Moulded parts that provide durable strain relief, protection and an environmental seal when used with an adhesive. Available in straight and right angled types, these chemical and abrasion resistant heat shrink boots are made from a tough modified elastomer, and meet the Def Stan 59-97 Issue 3 Type DE requirements. Other features include recommended shrink temperature 175°C, self-extinguishing to RK6713 and an electric strength of 12MV/m (min.) Meets specification VG95343 parts 6, 7, 8, 9. These boots can be used with spin coupling backshells, but may also be used wherever a connector offers a suitable rear mounting.
