Stainless Steel Liquid Level Sensor 20 cm - Durable Fuel and Water Measurement
The Stainless Steel STD-Type Liquid Level Sensor is a high-quality solution for accurately measuring liquid levels in various tanks. Whether it is for fuel, water, or other liquids, this sensor provides a reliable resistance value that can be directly connected to standard meters. Thanks to its stainless steel construction, this sensor is particularly suitable for marine applications, vehicles, and industrial installations.
Accurate Operation and Compatibility
This sensor operates based on a magnetic float that moves along the shaft. This system has no moving mechanical parts that can wear out, significantly extending its lifespan. With a resistance range of 240 Ohm when the tank is empty to 33 Ohm when the tank is full, this model seamlessly integrates with the most common European and American meter systems. The sensor is designed for 12V systems and has a total length of 20 centimetres.
Key Features
- High-Quality Material: Fully made of stainless steel for maximum corrosion resistance.
- Universal Mounting: Equipped with a standard mounting pattern for easy installation in existing tanks.
- Reliable Output: Stable signal transmission without fluctuations, ideal for moving vehicles or boats.
- Long Lifespan: The contactless measurement principle prevents internal wear due to friction.
Technical Specifications
In the list below, you will find the exact technical details of this model (article number HPY00001/20cm).
- Type: STD-Type Liquid Level Sensor
- Length: 20 cm (200 mm)
- Material: Stainless Steel
- Resistance Range: 240 Ohm (Empty) - 33 Ohm (Full)
- Voltage: 12 Volt
- Application: Fuel tanks, water tanks, and liquid reservoirs
- Article Number: HPY00001/20cm
