Souriau Sunbank by Eaton Circular Connector, 40 Contacts, Cable Mount, Plug, Male, IP67, Clipper Series - CL1P4201
Reliable circular connector with 40 contacts, IP67 rated for superior protection.
Manufacturer part number: CL1P4201
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Number of Contacts = 40
Mounting Type = Cable Mount
Plug/Socket = Plug
Contact Gender = Male
Termination Method = Crimp
IP Rating = IP67
Current Rating = 7.0A
Series = Clipper
Shell Size = 4
Housing Material = Thermoplastic
Strain Relief = No
Minimum Operating Temperature = -40°C
Cable sockets only mate with panel plugs or in-line coupler shells. Cable plugs only mate with panel sockets. Cable Shell. 180° screw coupling cable mount sockets. The unique contact retention system facilitates field maintenance and repair, enabling contacts to be loaded and unloaded by simply unlocking the contact retention plate. The assembled connector accepts a range of backshells. Contacts available seperately, typically 220-2810 or 175-3963.
