SMC Rc 1/8 Pneumatic Regulator - 0.01MPa to 0.8MPa, 1/8in, 1MPa max. input - IR1020-01

Port Connection = Rc 1/8
Maximum Outlet Pressure = 0.8MPa
Minimum Outlet Pressure = 0.01MPa
Maximum Input Pressure = 1MPa
Manufacturer Series = IR1000
Pressure Gauge Port Size = Rc 1/8
Port Connection Thread Size = 1/8in
Pressure Gauge Port Thread Size = 1/8in
Maximum Flow Rate = 4.4L/min
Port Connection Thread Standard = Rc
Minimum Operating Temperature = -5°C
Maximum Operating Temperature = +60°C
Overall Dimensions = 35 x 35 x 92mm

Precision regulator Regulating pressure range (MPa): 0.005 to 0.8 depending on model Compact and lightweight Bracket & pressure gauge can be mounted on either the front or back 2 air operated models
