The 12V tunnel-type gas extractor is the effective solution to keep the air fresh and free from potentially dangerous gases in the bilge, engine room, or closed compartments of your vessel.
Technical specifications
- Voltage: 12V DC
- Diameter: 76 mm
- Central motor: With a 6-blade fan for enhanced efficiency
- Material: Reinforced plastic body, resistant to marine corrosion
- Standard: Meets ISO 9097
- Protection: Ignition protected, prevents explosion risks in potentially hazardous atmospheres
- Mounting: Tunnel type, easy installation in ducts
Advantages
- Maximum safety against possible flammable gas leaks
- Compact and efficient design
- Suitable for prolonged use in demanding marine environments
Recommended applications
- Ventilation of bilges and battery compartments
- Gas extraction in engine rooms or galleys
- Aeration systems for motor and sailboats
Usage and maintenance tips
- Install the extractor in a splash-protected area, always fixed according to manufacturer instructions.
- Periodically check the condition of the electrical connections and ensure there are no blockages in the ducts.
- If excessive noise or airflow reduction is detected, clean the fan and check the correct operation of the motor.
Technical specifications table
| Voltage | 12V DC |
|---|
| Diameter | 76 mm |
|---|
| Standard | ISO 9097 |
|---|
| Protection | Ignition protected |
|---|
| Material | Reinforced plastic |
|---|
| Brand | Shurflo |
|---|
| Reference | SH277-3110 |
|---|
