Sensata Crydom Solid State Relay, 6 A Load, PCB Mount, 100 V dc Load, 28 V dc Control - CMXE100D6

Maximum Load Voltage = 100 V dc

UL. CMX-SIL SSR up to 10Adc. These MOSFET output solid state relays offer DC switching in a PCB style SIP package. Typically application is for the control of solenoid valves. They are also used to drive the DC coils on larger contactors in a microprocessor driven control system, and used for in DC lighting control. MosFET output Extra low on-state resistance Industry standard footprint DC Control Surge current peak: 100A Input-Output capacitance: 15pF Operating temperature range: -30 to +80°C Dimensions H33mm x W7.6mm x D43.1mm
