Sensata Crydom 1 Series Solid State Relay, 90 A Load, Panel Mount, 280 V rms Load, 32 V Control - D2490PG

Derating will limit the maximum load current at temperatures above 25 °C. UL Recognised; C-UL Recognised; VDE (including Protection). Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet. SSRs with Built In Overvoltage Protection AC Switching 10A to 125A. Overvoltage and transient protection Zero Voltage Switching Solid State reliability Status indicating LED Microprocessor compatible input Terminal Type Screw; Saddle Clamp Operating Temperature Range -40 to +80°C Dimensions: H22.9 x W45.7 x D58.4 Input to output Capacitance: 8pF
