Sensata Crydom 1 Series Solid State Relay, 10 A rms Load, Panel Mount, 280 V dc Load, 32 V dc Control - D2410K

Derating will limit the maximum load current at temperatures above 25 °C. UL recognised component for Canada and US, VDE. Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet. Crydom Series 1 Solid State Relays. Crydom Series 1 range of solid state relays offer a wide range of ratings from 10 A to 125 A at 24 V ac to 280 V ac. Crydom has incorporated many features within this particular range of panel mount solid state relays including AC or DC control and SCR output for heavy industrial loads. Both zero-crossing (resistive loads) and random-fire (inductive loads) output versions are available. Features and Benefits. 600 V blocking capacity. SCR Output for heavy industrial loads. Internal snubber circuitry. Filter, cover and thermal pads available. Terminal Type Screw; Saddle Clamp. Input-output Capacitance: 8 pF. Isolation Voltage 4 kVrms. Dimensions: H22.9 x D58.4 x W45.7mm
