Key Features:
- Designed for measuring the pressure of various fluids (gaseous or liquid) with low viscosity or corrosive to copper and tin alloys.
- Suitable for applications subjected to high vibrations.
- Equipped with a glycerine filling to dampen needle oscillations.
- Features a stainless steel case and a polycarbonate window for durability.
Technical Specifications:
- Pressure Range: 0 to 16 bar
- Accuracy Class: 1.6 (according to DIN 16005)
- Temperature Range: -20°C to +80°C
- Ingress Protection: IP 65
- Connection Type: Axial (rear)
- Connection Size: 1/4"
- Dial Diameter: 63 mm
- Window Material: Polycarbonate
- Filling Liquid: Glycerine (98% distilled)
Materials:
- Case: Stainless steel
- Window: Polycarbonate
- Connection: Brass (OT59)
Dimensions:
- Dial Diameter: 63 mm
- Depth: Approximately 74 mm
- Weight: Approximately 0.21 kg
Compatibility Information:
- Suitable for measuring the pressure of various fluids (gaseous or liquid) with low viscosity or corrosive to copper and tin alloys.
- Particularly adapted for devices subjected to high vibrations.
