Key Features:
- Glycerin-filled dial for enhanced stability and protection against vibrations.
- Axial (rear) connection for easy installation.
- Dual scale display in bar and psi for versatile pressure readings.
- Suitable for measuring pressures in both liquid and gaseous media.
Technical Specifications:
- Pressure Range: 0 to 2.5 bars
- Diameter: 63 mm
- Connection Type: Male BSP 1/4"
- Accuracy Class: 1.6% of full scale
- Temperature Range:
- Ambient Temperature: -20°C to +60°C
- Fluid Temperature: Up to +60°C
- Ingress Protection: IP 65
Materials:
- Case: Stainless steel (AISI 304)
- Bourdon Tube: Brass
- Window: Polycarbonate
- Dial: Aluminum with white lacquer
- Pointer: Aluminum with black lacquer and chrome center
Dimensions:
- Overall Diameter: 63 mm
- Depth: Approximately 85 mm
- Width: Approximately 75 mm
- Height: Approximately 34 mm
Compatibility Information:
- Ideal for applications requiring precise pressure measurements in environments with vibrations or pulsations.
- Compatible with fluids that are non-corrosive and have low viscosity.
Additional Details:
- The glycerin filling dampens vibrations, providing a more stable and accurate reading.
- The IP 65 rating ensures protection against dust and water ingress, making it suitable for various industrial environments.
