Schneider Electric, SP 2 Position 90° Changeover Cam Switch, 690V ac, 5.6A - K1B011UCH

Pole and Throw Configuration = SP
Normal State Configuration = NO/NC
Maximum Current = 5.6A
Maximum Voltage = 690V ac
Number of Positions = 2
Terminal Type = Screw
Angle of Throw = 90°
Length = 78mm
Width = 45mm
Depth = 100.5mm
Better World Product = Yes
Dimensions = 78 x 45 x 100.5mm

Industrial Cam Switches. Control circuits (EN60947-5-1) or power circuits (EN60947-3) IP65 single 22mm diameter fixing hole Finger-proof terminals Operating temperature -25 to +55°C Slow break contacts with positive opening operation Thermal current rating: 12A free air, 10A enclosed Nominal voltage: 230V; 400V
