Schneider Electric 250V ac Shunt Trip Circuit Trip for use with DIN rail mounting support - A9E18071

Range = Acti 9A
Series = iSSW
For Use With = DIN rail mounting support
Type = Shunt Trip
Rated Control Voltage = 250V ac

The Schneider Electric Acti 9 iSSW is a linear switch used for the manual control of electric circuits. It is a 2 positions switch with 2 changeover contact (2 C/O). The phase-separated wall can be divided to allow all the types of com busbar to pass through. It comes with staggered terminals to simplify connection. The tightening torque of connection is 1N.m for PZ1 screwdriver type. It complies with IEC 60669-1 and IEC 60947-5-1 standards.The connection allows rigid copper cables from 0.5mm² minimum to 2x2.5mm² maximum The connection allows flexible or with ferrule copper cables from 0.5mm² minimum to 2x2.5mm² maximum The number of cycles open and close (O-C) is 30000 The width in 9mm pitc
