Product Description
ONE is a general purpose laminating resin with a high biobase content for composite laminating, coating and bonding applications.
This system features faster speed, low viscosity, fast debubbling, ideal for fibre reinforced composite lamination and coating.
ONE is a USDA-certified BioPreferred® product with a 30% biobase content.
Usage
- Wood
- Coating
- Marine application
- Gluing
Consumption
A 6L kit = 32.5m². Consumption is reduced by 50% on porous supports or fibre reinforcement.
Working Temperature
Optimal temperature from 21°C to 30°C.
Environment
- BIO-REFINERY: Traditional raw materials based on petroleum carbon are replaced by materials based on renewable vegetal carbon or co-produced by other industrial processes.
- RESIN FORMULATION: Green chemistry techniques ensure energy-efficient formulation and fewer harmful by-products.
- SUPER SAP: Technology that saves energy, minimizes harmful by-products and reduces greenhouse gas emissions.
Application Tips
- For best results, measure both components by weight to within 5% of the recommended mixing ratio.
- Always mix the product for at least two minutes, scraping the container to ensure thorough mixing.
- Use products in a controlled environment; avoid high humidity and low temperatures.
- Animes, a by-product of the curing process, appear as a waxy film on the cured epoxy and are more visible in cool, damp conditions. It can clog sandpaper and inhibit adhesion.
- The amine is water soluble and is easily removed with clean water (no solvent) and an abrasive pad.
- For good adhesion, epoxy bonding surfaces must be clean, dry and sanded.
- If you are unfamiliar with the product, create small test samples before starting a larger scale project.
Mechanical Characteristics
Tensile modulus (ASTM D638) | 2.7 GPa |
Tensile strength (ASTM D638) | 53.2 MPa |
Elongation (ASTM D638) | 6% |
Flexural Modulus (ASTM D790) | 2.5 GPa |
Flexural strength (ASTM D790) | 82.1 MPa |
Compressive strength (ASTM D695) | 77.9 MPa |
Ultimate Tg | 63°C |
Hardness (shore D) | 70-80 |
Processing Characteristics
Mixing ratio (by volume) | 2:1 |
Mixing ratio (by weight) | 100:43 |
Viscosity (A/B/Mixed at 25°C) | 1870/120/1020 mPas |
Component density (density at 25°C) | 1.14 (resin), 0.98 (hardener) gcm-3 |
Density of the mixture (density at 25°C) | 1.09 gcm-3 |
Operating time (at 25°C) | 18 minutes |
Dry to the touch (at 35°C) | 3 hours |
Recommended full cure | 7 days at 25°C |
Environmental Features
VOC content (ASTM D2369) | 21.0 g/l |
Bio-based carbon content (ASTM D6866) | 28% |
