PRO-SET's INF-114 Infusion Epoxy Resin
PRO-SET's INF-114 infusion epoxy resin is an ultra-low viscosity system, accompanied by a range of hardeners designed to meet the demands of modern infusion processes. These epoxies produce lightweight composites with superior performance, capable of withstanding long-term recurring loads in demanding environments. They can be post-cured to further optimize performance, and develop excellent physical properties at room temperature.
Hardeners
- Fast (210)
- Medium (211)
- Slow (212)
- Super-slow (213)
Packaging
- Hardener packaging: available in 1.37kg, 6.86kg, 61.65kg and 274kg
- Resin packaging: available in 5kg, 25kg, 225kg and 1000kg
Mixing Ratios
- Mixing ratio by weight: 3.65:1 (Resin:Hardener)
- Mixing ratio by volume: 3:1 (Resin:Hardener)
Hardness
Hardness (Type D): 86
Technical Properties
| Technical properties INF-114 / INF-210 (72°F (22°C) x 4 weeks) |
| Mixed viscosity 22°C: 304 mPas |
| Compressive strength: 14.7 MPa |
| Tensile strength: 8.670 MPa |
| Tensile elongation: 2% |
| Flexural strength: 13.5 MPa |
| Ultimate Tg by DMA: 165°C |
| Technical properties INF-114 / INF-211 (72°F (22°C) x 4 weeks) |
| Mixed viscosity 22°C: 296 mPas |
| Compressive strength: 14.7 MPa |
| Tensile strength: 7.770 MPa |
| Tensile elongation: 1.7% |
| Flexural strength: 12.3 MPa |
| Ultimate Tg by DMA: 158°C |
| Technical properties INF-114 / INF-212 (72°F (22°C) x 4 weeks) |
| Mixed viscosity 25°C: 294 mPas |
| Compressive strength: 14.6 MPa |
| Tensile strength: 8 MPa |
| Tensile elongation: 1.8% |
| Flexural strength: 12.8 MPa |
| Ultimate Tg by DMA: 156°C |
| Technical properties INF-114 / INF-213 (72°F (22°C) x 4 weeks) |
| Mixed viscosity 25°C: 325 mPas |
| Compressive strength: 15 MPa |
| Tensile strength: 7.9 MPa |
| Tensile elongation: 1.8% |
| Flexural strength: 11.9 MPa |
| Ultimate Tg by DMA: 155°C |
For further information, please consult the product data sheet.
