Maximum Working Pressure: 700 bar
Capacity Class: 10 imperial tons
Maximum Cylinder Capacity (Advance): 101 kN
Stroke (Race): 54 mm
Height (Retracted Stem - A): 121 mm
Height (Extended Rod - B): 175 mm
Return Type: Single-acting, return spring
Piston Type: Full
Material: Steel
Effective Cylinder Surface (Advance): 14.4 cm²
Oil Capacity (Advance): 78 cm³
Surface Finish: Painted
Coupler Type: CR400
Weight: 2.3 kg
