Key Features:
- Crystal Clear Depth Readout: Provides accurate and easily readable depth measurements.
- Shallow and Deep Anchor Alarms: Alerts for both shallow and deep anchor conditions.
- Minimum Depth Display: Displays the minimum depth recorded.
- Red Backlighting: Enhances visibility in low-light conditions.
- Low Power Consumption: Extends battery life.
- Large Controls: Facilitates easy operation at sea.
- SeaTalk Network Interface: Allows integration with other Raymarine instruments.
- Integrated Sensor Interface: Supports connection with compatible transducers.
- Surface or Trunnion Mounting: Offers flexible installation options.
Technical Specifications:
- Display Dimensions: 128 mm (5.04 in) in length, 72 mm (2.83 in) in height, and 35 mm (1.4 in) in depth.
- Operating Voltage: 10 V DC to 16 V DC.
- Current Consumption: Typical: 35 mA; Maximum: 100 mA.
- Operating Temperature Range: 0°C to +70°C (32°F to 158°F).
- Storage Temperature Range: -30°C to +70°C (-22°F to 158°F).
- Waterproof Rating: IPx6.
- Relative Humidity: Up to 93%.
Materials:
The display unit is constructed with durable materials suitable for marine environments, ensuring longevity and resistance to corrosion.
Dimensions:
- Display Unit: 128 mm (5.04 in) in length, 72 mm (2.83 in) in height, and 35 mm (1.4 in) in depth.
- Transducer Cable Length: 13 meters.
Compatibility Information:
The i40 Depth Display Pack is compatible with Raymarine's SeaTalk network, allowing integration with other Raymarine instruments and autopilots. It can function as a master or repeater, hosting its own transducer or repeating data from another SeaTalk network device. For integration with SeaTalkng devices, a SeaTalk to SeaTalkng Converter Kit (E22158) is required.
