The PREVOST prevoS1 Air Blow Gun with OSHA Composite Nozzle is a high-performance pneumatic tool designed for efficient and safe air blowing applications. Its ergonomic design and advanced features make it suitable for various industrial and workshop environments.
- Ergonomic Design: The blow gun features a comfortable grip, ensuring ease of use during extended periods.
- OSHA Compliant Nozzle: Equipped with an OSHA-compliant composite nozzle, it offers a high flow rate and is scratch-resistant, protecting surrounding surfaces from damage.
- Low Air Consumption: Designed to minimize air consumption, promoting energy efficiency.
- Leak-Free Operation: The integrated plug system ensures a hermetically sealed connection, eliminating the risk of leaks and enhancing safety.
- Durable Construction: Constructed with a polyamide composite body, the blow gun is robust, lightweight, and insulated, providing resistance to abrasion, impacts, and chemical exposure.
Technical Specifications
- Maximum Operating Pressure: 12 bar (174 psi)
- Recommended Operating Pressure: 6 bar (87 psi)
- Operating Temperature Range: -15°C to +70°C
- Air Consumption at 6 bar: 13 Nm³/h
- Blowing Force at 6 bar: 248 g
- Dynamic Pressure at 10 mm: 2.3 bar
- Noise Level at 6 bar: 85 dBA
Materials
- Body: Polyamide composite
- Nozzle: Composite material compliant with OSHA standards
Dimensions
- Hose Diameter: 5 x 10 mm
- Hose Length: 0.5 meters
Compatibility Information
- Connection Profile: Compatible with all major connection profile standards, including ARO 6 (BSP)
- Coupling Compatibility: When connected directly into a prevoS1 quick-safety coupling, it forms a seamless, leak-free union.
