Portescap Micro Linear Actuator, 18.83mm, 12V dc, 34.2N - 26DBM20D2U-K
Compact micro linear actuator with 18.83mm stroke and 34.2N force for precise control.
Manufacturer part number: 26DBM20D2U-K
Free shipping
Only Ships to: France, Monaco, Italy For shipping outside these regions, please contact customer support.
Actuator Type = Micro Linear Actuator
Maximum Stroke Length = 18.83mm
Maximum Load = 34.2N
Input Voltage = 12V dc
Motor Technology = Stepper Motor
Miniature Linear Actuators. A non-captive linear actuator that provides a long stroke length and up to 128 oz of linear force in a 26 mm frame size. The 7.5 degree step angle and option of 0.0005" lead screw pitch options allows for greater positional resolution. Features and Benefits. High continuous linear force output for size. Digitally controlled - easy to use with a micro processor. Cost effective - compact design, lower integration cost. Maintenance free - no brushes to replace. Unipolar and bipolar winding options. Captive and non-captive designs. Long life - ball bearing design. Product Application Information. Motors for medical pipettes. Damper actuation. Flap actuation. Printers and copiers. Switching systems
