Parker Origa G 1/8 Pneumatic Regulator - 0bar to 8bar, 1/8in, 10bar max. input - PS120001-080-000
Achieve precise pressure control with the Parker Origa G 1/8 Pneumatic Regulator.
Manufacturer part number: PS120001-080-000
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Port Connection = G 1/8
Maximum Outlet Pressure = 8bar
Minimum Outlet Pressure = 0bar
Maximum Input Pressure = 10bar
Manufacturer Series = Piezo
Port Connection Thread Size = 1/8in
Maximum Flow Rate = 350L/min
Typical Flow Rate = 200L/min
Integral Check Valve = Without Check Valve
Port Connection Thread Standard = G
Minimum Operating Temperature = 0°C
Maximum Operating Temperature = +50°C
The Regulator is supplied without the Mounting Block and Cable. To order a Piezo Regulator, Mounting Block and Cable please quote stock number ; 290-3406 290-3406. G 1/8 Piezo Type Pressure Regulator. Compact, lightweight design Temperature range: 0° to +50°C Typical flow: 130l/min Fast response: 42Hz High precision and reliability Low power consumption Integrated closed loop pressure measurement Requires dry air filtered to 5µm; 1.5 to 10 bar Weight: 180g
