Osculati - Watertight surface mount circuit breaker 150 A - 02.711.40

Resettable and releasable via a specific lever, they simultaneously serve as both fuse and switch. Manufactured in accordance with USA standards SAEJ1171 and CE 28846 “Vapor Proof”, capacity 3000 operating cycles. Allowed voltage: max 48 V,Enlarged version, electrical terminals at 5/16” (instead of 1/4”) to facilitate cable connection. The recessed model requires a simple circular hole for installation. IP66 Waterproof. From 100 A to 200 A can also be used as a general battery disconnect.Maximum voltage capacity:5000A 14VDC;3000A 28VDC;1500A 48VDC.Operating temperature: -40C° / 85C°.
