Key Features:
- Constructed from mirror-polished stainless steel for enhanced durability and aesthetic appeal.
- Equipped with a braked central axle to effectively dampen vibrations, reducing noise and wear.
- Symmetrical design allows for flexible installation, accommodating various mounting configurations.
Technical Specifications:
- Material: Stainless steel
- Finish: Mirror polish
- Type: Symmetrical hinge
- Axle (Pin) Options:
- Standard pin
- Reversed pin
- Central pin
- Thickness: 2 mm (excluding the pin)
- Dimensions: 137 mm x 39 mm
- Vibration Dampening: Braked central axle
- Mounting: Requires 6 screws (not included)
Materials: High-quality stainless steel ensures resistance to corrosion and longevity, making it suitable for marine environments.
Dimensions:
- Length: 137 mm
- Width: 39 mm
- Thickness: 2 mm (excluding the pin)
Compatibility Information:
- Ideal for use on boats, yachts, and other marine vessels.
- Suitable for applications such as cupboard doors, furniture, shelves, and cooler hatches.
- Available in three pin configurations to suit different installation requirements:
- Standard pin
- Reversed pin
- Central pin
Additional Details:
- The braked central axle not only dampens vibrations but also enhances the hinge's stability and performance.
- The mirror-polished finish provides a sleek appearance and additional protection against the elements.
