Key Features:
- Designed for recessed mounting with a frontal orientation.
- Provides white or blue illumination.
- Constructed from chrome-plated brass for durability.
- Pressure fitting installation for secure mounting.
- Waterproof with an IP65 rating, suitable for marine environments.
Technical Specifications:
- Voltage: 12 V
- Power Consumption: 0.23 W
- Luminous Flux: 1.6 lumens
- Color Temperature: 5500-6300 K
- LED Beam Angle: 30°
- Number of LEDs: 1
- Light Color: White or Blue
- Recessed Mounting Diameter: 25.4 mm
- Exterior Dimensions: 30 x 30 mm (square) or Ø 32 mm (round)
Materials:
- Housing: Chrome-plated brass
Dimensions:
- Recessed Mounting Diameter: 25.4 mm
- Exterior Dimensions: 30 x 30 mm (square) or Ø 32 mm (round)
- Height: 10 mm
- Width: 10 mm
- Length: 5 mm
Compatibility Information:
- Suitable for recessed mounting with a 25.4 mm diameter hole.
- Compatible with 12 V electrical systems.
Additional Details:
- Available in both square and round front orientations.
- Light color options include white and blue.
- Designed to enhance onboard lighting with a compact and elegant design.
