Compatible with NMEA2000 / J1939 / analog protocols.To be used with any outboard / inboard engine except Mercury with SMARTCRAFT protocol.Functions: speedometer via GPS signal (Knots, km/h, MPH); tachometer with selectable full scale from 3000 to 8000 RPM; hour meter; integrated GPS antenna; fuel level + 10% alarm. Selectable at will 0-190 / 240-33 ohm; oil pressure + alarm at 0.7 bar (preferred scale bar/psi selectable); water temperature + alarm at 95° (Celsius/Fahrenheit scale selectable).Backlit (clearly legible even when exposed to sunlight), adjustable lighting. Red and yellow backlit dial. Power supply 9/32 V. Resolution: 432x432 pixel.Supplied with: 1m 5-pole NMEA cable with standard end connector, 1m 6-pole-analog cable.
