Osculati - Italwinch Smart V windlass 500 W 12 V - 6 mm ISO low - 02.402.01

Name: Osculati - Italwinch Smart V windlass 500 W 12 V - 6 mm ISO low - 02.402.01
SKU: 02.402.01
Price: 969.00 EUR
Availability: InStock

Brand: Osculati

Powerful 500W windlass for effortless anchoring on boats up to 8m.

Manufacturer part number: 02.402.01

GTIN: 8033137070891

Vendor: Omax Marine Group

Select variant:

€969.00 incl tax

Qty:

i h

Delivery date: 3-5 days

Polished AISI316 stainless steel body. Vertical windlass for easy installation. It uses chain or rope/chain. Built-in chain counter sensor. IP67 watertight motor. For boats up to 8 m.

Specifications

Property	Value
Motor - W	500
Current draw A	60
Gypsy Øchain mm	6
Max pull kg	285
Working load kg	90
Line speed m / min	23

Attachments

02.402.xx SmartV.pdf
