The HX range offers a completely new project both inside and outside: the result is a new, robust and reliable windlass with in-line motor and worm wheel gearbox.The HX features an aluminium frame designed to withstand years of heavy loads. The covers are made of polymer.2 options to choose as Gypsy: 6/7 mm or 8 mm, motors of 500 and 800 W.Waterproof unit IP67.Quiet under load.A manual 'free fall' kit is available to be applied over the sprocket.
Specifications
| Property | Value |
|---|
| Motor - W | 800 |
| Gypsy - chain Ø mm | 8 |
| Pull kg - max | 1065 |
| Pull kg - continuous | 267 |
| Line speed m/min - max | 21 |
| Current draw A | 105 |
| Recommended circuit breaker A | 90 |
| For boats | 9 to 13 m |
