Key Features:
- Super-Compact Design: Ideal for installation on dashboards or bulkheads, saving valuable space.
- Three Position Switch: OFF, ON, and OUT positions. The OUT position allows for the removal of the knob, serving as an anti-theft device.
- High Capacity: Supports a continuous capacity of 100A and an intermittent capacity of 150A, suitable for 12V or 24V boat batteries.
- Easy Installation: Designed for straightforward mounting on bulkheads, dashboards, or control panels.
Technical Specifications:
- Maximum Continuous Capacity: 100A
- Maximum Intermittent Capacity: 150A
- Overall External Diameter: 45 mm
- Hole Diameter: 26 mm
- Useful Neck Length: 11 mm
- Terminal Diameter: 6 mm
- Voltage Compatibility: Suitable for 12V or 24V systems
Materials:
- Housing: Durable materials suitable for marine environments (specific material details not provided in the available sources).
- Key: Nickel-plated brass removable key for enhanced durability and corrosion resistance.
Dimensions:
- Flange Diameter: 45 mm
- Neck Diameter: 26 mm
- Neck Length: 11 mm
- Terminal Diameter: 6 mm
Compatibility Information:
- Voltage Systems: Compatible with 12V and 24V boat battery systems.
- Mounting Locations: Suitable for installation on dashboards, bulkheads, or control panels.
Additional Details:
- Anti-Theft Feature: The removable key serves as an anti-theft device, enhancing security when the boat is unattended.
- CE Certification: CE-approved in compliance with directive 94/25/CE, ensuring adherence to European safety standards.
