Key Features:
- Designed for passing straps or serving as a starting point.
- Made from high-quality AISI 316 stainless steel for enhanced durability and corrosion resistance.
- Available in multiple sizes to accommodate different strap widths.
Technical Specifications:
- Material: AISI 316 Stainless Steel
- Dimensions:
Overall Size: 48 mm (length) x 15 mm (width)
Strap Passage: 30 mm
Hole Center-to-Center Distance: 38 mm
Hole Diameter: 4 mm
- Weight: Approximately 0.025 kg
- Mounting: Designed for installation using screws or rivets.
Materials:
- Constructed entirely from AISI 316 stainless steel, ensuring resistance to corrosion and suitability for marine environments.
Compatibility Information:
- Specifically designed for straps with a width of 30 mm.
- Suitable for various marine applications requiring secure strap passage or anchoring points.
Additional Details:
- Part of a series of strap passage rings available in different sizes:
30 mm passage: 06.701.30
40 mm passage: 06.701.40
50 mm passage: 06.701.50
- Sold individually.
