Key Features:
- Integrated Autoclave Pump: Equipped with Osculati's 16.503.12 autoclave water pump, designed for single outlet use.
- Adjustable Height: The tank can be rotated 90°, allowing height adjustment between 26 cm and 34 cm to suit installation requirements.
- Versatile Installation: Can be installed with a base of 340x400 mm (height 260 mm) or 400x260 mm (height 340 mm).
- Mounting Preparedness: Prepared for mounting with Osculati's 52.195.00 bracket.
Technical Specifications:
- Capacity: 32 liters
- Pump Flow Rate: 3.8 liters per minute at 12V
- Outlet Diameter: 10 mm
- Inlet Connection Diameter: 38 mm
- Vent Diameter: 16 mm
- Standard Thickness: 4 mm (±5%)
- External Dimensions: 400x260x340 mm
Materials:
- Tank Construction: Made of durable polyethylene
- Pump Construction: Specific material details not provided
Dimensions:
- Height: Adjustable between 26 cm and 34 cm
- Base Dimensions: 340x400 mm or 400x260 mm
- External Dimensions: 400x260x340 mm
Compatibility Information:
- Mounting Bracket: Compatible with Osculati's 52.195.00 bracket
- Installation Bases: Supports two base configurations: 340x400 mm (height 260 mm) and 400x260 mm (height 340 mm)
Additional Details:
- Standard Thickness: 4 mm (±5%)
- Installation Note: The installer or designer is responsible for ensuring that both the tank and its mounting systems comply with the required use. Technical support should be requested if necessary.
