Key Features:
- High-Grade Ceramic Insulator: Utilizes high-grade alumina silicate ceramic to create a stronger insulator for optimal dielectric performance.
- Triple Gasket Sealing: Prevents combustion gas leakage, ensuring reliable engine performance.
- Solid Copper Core: 98% pure copper core offers superior heat dissipation and conductivity.
- Trivalent Metal Plating: Provides superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal.
Technical Specifications:
- Thread Size: 14mm
- Thread Pitch: 1.25mm
- Seat Type: Tapered
- Resistor: Yes, with a resistor value of 5K Ohm
- Reach: 11.6mm (0.460 inches)
- Hex Size: 5/8 inches (16mm)
- Gap: 0.031 inches (0.8mm)
- Center Electrode Material: Nickel
- Ground Electrode Material: Nickel
- Heat Range: 6
- Electrical Terminal Type: Non-Removable Nut
Materials:
- Center Electrode Core: Nickel
- Ground Electrode Core: Nickel
- Insulator: High-grade alumina silicate ceramic
- Resistor: 5K Ohm
Dimensions:
- Overall Length: Approximately 53mm
- Thread Reach: 11.6mm (0.460 inches)
- Hex Size: 5/8 inches (16mm)
Compatibility Information:
This spark plug is compatible with various OMC inboard engines, including models from Indmar, Marine Power, Mercruiser, OMC, Redline, and Volvo Penta.
