Key Features:
- Durability: Engineered for extended service life and optimal performance in marine environments.
- Compatibility: Designed to fit a wide range of outboard motors from Mariner, Suzuki, Tohatsu, and Yamaha.
- Construction: Features a solid copper core for superior heat dissipation and conductivity.
Technical Specifications:
- Thread Size: 14mm
- Thread Pitch: 1.25mm
- Seat Type: Gasket
- Resistor: Yes, with a value of 5,000 Ohms
- Reach: 12.7mm (1/2")
- Hex Size: 21mm (13/16")
- Gap: 0.039" (1.0mm)
- Center Electrode Material: Nickel
- Ground Electrode Material: Nickel
- Insulator Height: 55mm
- Electrical Terminal Type: Removable Nut
Materials:
- Center Electrode Core: Solid 98% pure copper
- Center Electrode Tip: Nickel
- Ground Electrode Core: Nickel
- Ground Electrode Tip: Nickel
Dimensions:
- Overall Height: 55mm
- Hex Size: 21mm (13/16")
Compatibility Information:
The NGK BR8HS-10 spark plug is compatible with various outboard motors from the following manufacturers:
- Mariner:
- 60HP 2-Cylinder models: 60E, 60EL
- Suzuki:
- DT40C, DT40CR, DT40TC (1998 and after)
- DT50M, DT50W (2001 and after)
- DT55TC, DT55CRQ (1998 and after)
- DT60C (2001 and after)
- DT60C, DT60TC
- DT75, DT85 (1993 - 2000)
- DT90TC, DT100TC (1998 and after)
- DT100 (1989 - 1990)
- DT115, DT115C (2001 and after)
- DT115S, DT115STC (1996 and after)
- DT140 EFI (1996 and after)
- DT140T, DT140TC (2001 and after)
- DT150 (1987 - 2002)
- DT175, DT200 (1989 and after)
- DT200G, DT200T, DT200TC, DT200V
- DT225 (1987 and after)
- Tohatsu:
- M50D, M60A, M60B, M60C (1997 and after)
- M70A, M70A2, M70B (1997 and after)
- M80A, M90A, M115A, M120A, M140A
- Yamaha:
- 25X, 30G, 30H, 40Y
- 50D, 50G, 50H, 50T, 55B, 55D (1990 and after)
- 60F, 60T, 70B, 70C, 70T, 70ETO, 75A, 75B, 75C, 80A, 85A
- 90A, 90T, 100A, 115B, 115BETO, 115C, 115F, 115T
- Vmax 150TRP, Vmax 200
- 200D V6 3.3L
