The Neoprene Joint 3/8" is a closed-cell neoprene gasket designed for sealing applications where flanged connections are used, such as in duct systems. It effectively prevents air leakage, thereby reducing energy waste and noise.
- Material: Black, continuous, closed-cell neoprene rubber.
- Density: 88-120 kg/m³.
- Hardness: 50 ± 10 Shore A.
- Compression-Deflection at 25%: 5 - 9 psi.
- Compression Set at 50%: ≤ 25%.
- Water Absorption: < 10%.
- Fluid Immersion: < 100%.
- Tear Strength: 12 lbs/in.
- Tensile Strength: 75 psi minimum.
- Elongation: 100% minimum.
- Flammability: FM VSS 302, UL 94 V-0, 5 VA, HF-1, HBF.
- Temperature Range: -20°F to 160°F (maximum), 200°F intermittent.
Technical Specifications
- Length: 25 feet.
- Width: 3/4 inch.
- Thickness: 3/8 inch.
Materials
Neoprene Rubber: Provides excellent resistance to oil and fuel, ensuring durability and longevity in various sealing applications.
Dimensions
- Length: 25 feet.
- Width: 3/4 inch.
- Thickness: 3/8 inch.
Compatibility Information
This neoprene gasket is suitable for use in duct systems where flanged connections are present, effectively sealing gaps and irregularities to prevent air leakage.
