Generators specifications
Phase: 3
Frequency: 60 Hz
RPM: 1800 rpm
Power LTP: 108 KW
Power PRP: 98.4 KW
Load Volts: 120 - 208 - 416
Load Amps: 341 - 170 l/h
Engine
Base: John Deere
Configuration: 4 cylinders in line- 4 stroke Diesel
Regulation: Electronic
Displacement: 4480 l
Dimensions
Length mm [in]: 1590 [62.5]
Width mm [in]: 770 [30.3]
Height mm [in]: 965 [37.9]
Weight kg [lbs]: 1000 [2204]
