Generators specifications
Brand: Mecc Alte
Phase: 1
Frequency: 60 Hz
RPM: 1800 rpm
Power LTP: 9.3 KW
Power PRP: 8.9 KW
Load Volts: 120 - 240
Load Amps: 37.1 l/h
Engine
Base: Kubota
Configuration: 3 cylinders in line- 4 stroke Diesel
Regulation: Mechanical
Displacement: 1.123 l [68.5 in3 ]
Dimensions
Length mm [in]: 925 [36.4]
Width mm [in]: 580 [22.8]
Height mm [in]: 640 [25.1]
Weight kg [lbs]: 271 [597]
